特點與用途/Features & A
l 高度低，變形量小
l 不銹鋼材料
l 拉壓雙向
l 主要用于推、拉力計，料斗秤，各種工業稱重系統等
l low profile，small deflection
l Made of stainless steel
l Tension and compression application
l Mainly used for pull and push dynamometer,hopperscale and industrial measuring system
|
參數
|
Specifications
|
技術指標/Technique
|
|
額定容量
|
Capacity
|
1.5,2,3,5kN
|
|
輸出靈敏度
|
Rated output
|
1.5±10%mV/V
|
|
零點輸出
|
Zero balance
|
±2% F.S.
|
|
非線性
|
Non-linearity
|
0.2%F.S.
|
|
滯后
|
Hysteresis
|
0.2%F.S.
|
|
重復性
|
Repeatability
|
0.2%F.S.
|
|
蠕變（30min）
|
Creep(30min)
|
0.05%F.S.
|
|
溫度靈敏度漂移
|
Temp.effect on output
|
0.05%F.S./10℃
|
|
零點溫度漂移
|
Temp.effect on zero
|
0.05%F.S./10℃
|
|
輸入電阻
|
Input impedance
|
385±10Ω
|
|
輸出電阻
|
Output impedance
|
350±5Ω
|
|
絕緣電阻
|
Insulation
|
≥2000MΩ/100VDC
|
|
激勵電壓
|
Recommended excitation
|
5V~10V
|
|
最大激勵電壓
|
Maximum excitation
|
15V
|
|
溫度補償范圍
|
Compensated temp range
|
-10~60℃
|
|
工作溫度范圍
|
Operation temp range
|
-20~80℃
|
|
安全超載
|
Safe overload
|
120%F.S.
|
|
極限超載
|
Ultimate overload
|
150%F.S.
|
|
電纜線尺寸
|
Cable size
|
φ3×1500mm
|
|
單件重量
|
Weight approx.
|
0.25kg
|
|
材料
|
Material
|
Stainless Steel（不銹鋼）
|
|
防護等級
|
IP Class
|
IP67
|
