額定載荷 Rated Load
|
20t
|
|
額定輸出 Rated Output
|
2.0000±0.001MV/V
|
|
綜合誤差 Total Error
|
±0.02%F.S
|
|
蠕變 Creep(30minutes)
|
±0.02%F.S
|
|
推薦工作電壓 Recommended Excitation Voltage
|
5V～18V(AC or DC)
|
|
最大工作電壓 Maximum Excitation Voltage
|
24V(AC or DC)
|
|
零點平衡 Zero Balance
|
±1%F.S
|
|
輸入阻抗 Input Impedance
|
775±5Ω
|
|
輸出阻抗 Output Impedance
|
700±2Ω
|
|
絕緣阻抗 Insulation Impedance
|
≥5000MΩ
|
|
安全過載率 Safe Overload
|
150%F.S
|
|
極限過載率 Ultimate Overload
|
200%F.S
|
|
工作溫度范圍 Operating Temperature Range
|
(-30～+70)℃
|
|
溫度補償范圍 Compensated Temperature Range
|
(-20～+60)℃
|
|
輸出溫度影響 Temperature Effect On Load
|
±0.02%F.S/10℃
|
|
零點溫度影響 Temperature Effect On Zero
|
±0.02%F.S/10℃
|
|
材質(zhì) Construction
|
合金鋼 Alloy Steel
|
|
防護等級 Protection Class
|
IP68&IP67
|
|
引用標(biāo)準(zhǔn) Citation
|
GB/T7551-2008/OIML R60
|
|
接線方式 Mode of Connection
|
輸入+:紅 Input+:Red
輸入-:綠 Input-:Green
輸出+:黃 Output+:yello
輸出-:白 Output-:White
|
